suspension cranes

Suspension cranes are efficient because they can cover almost the entire floor area. These cranes travel on crane tracks on the ceiling so that a maximum lifting height can be achieved even with a relatively low hall. By means of coupling stations, these cranes can be directed to another track or the trolley can take a different route via a monorail. In this way, loads can easily be moved from hall A to hall B, for example, without having to unhook.

Single- and double girder suspension cranes have a modular structure and are manufactured in series, guaranteeing high quality assurance. This means that many years after delivery, an extension to the existing system can be realized without any problems.

CHARACTERISTICS

• Lifting capacities up to approx. 6.3 tons
• Span of approx. 14 meters
• Design-optimized crane undercarriage
• Action directly at the wall through individual adjustment of the overhang
• Crane carriages made of torsionally rigid welded box construction
• Favorable approach dimensions due to maximum surface area
• Power supply via flat cable or energy chain
• Fixed control or DEMAG radio control
• According to DIN 15018
